Remark:
1) In case of no tolerance shown in outline dimension:outline dimension ≤1mm,tolerance should be ±0.2mm;outline dimension＞1mm and≤5mm,tolerance should be±0.3mm;outline dimension＞5mm,tolerance should be±0.4mm.
2) The tolerance without indicating for PCB layout is always±0.1mm.
Notes:
1) To avoid using relay under strong magnetic field which will changethe parameters of relays such as pick-up voltage and drop-out voltage.
2) Relays may be damaged because of falling or when shocking conditions exceed the requirement.
3) About preferable condition of operation,storage and transportation.please refer to “Explanation to terminology and guidetines of relay”.
4) For unenclosed type,beaucause there is no cover protection,the products may be contaminate by particles during transportation assembly of usage,which may cause relay failure,so the produces should be effectively protected at customer side ,JINTIAN suggest to use JT2150/JT2160 type,if no other special requirement
5) AgSnO contact can be represented as “(T)” after periodic code.
6) The customer special requirement express as special code after evaluating by JINTIAN.
